| 導線截面6～10mm2（美國線規8) 最大電流：Imax=62A 材質：紫銅 材料厚度：1.2mm |
|
型號 |
美制螺栓號 |
螺栓口直徑 |
尺寸 |
|
B |
L |
F |
E |
Dφ |
dφ |
|
|
#8 |
4.3 |
8.8 |
23.8 |
9.3 |
8.5 |
7.2 |
4.5 |
|
|
#10 |
5.3 |
8.8 |
23.8 |
11.1 |
|
|
#10 |
5.3 |
12.0 |
23.8 |
9.3 |
|
|
#10 |
5.3 |
15.0 |
29.8 |
13.8 |
|
|
1/4 |
6.4 |
12.0 |
23.8 |
9.3 |
|
|
1/4 |
6.4 |
15.0 |
29.8 |
13.8 |
|
|
5/16 |
8.4 |
15.0 |
29.8 |
13.8 |
|
|
3/8 |
10.5 |
15.0 |
29.8 |
13.8 |
|
|
1/2 |
13.0 |
20.0 |
33.5 |
15.0 | | | |
| 導線截面10～16mm2（美國線規6) 最大電流：Imax=88A 材質：紫銅 材料厚度：1.4mm |
|
型號 |
美制螺栓號 |
螺栓口直徑 |
尺寸 |
|
B |
L |
F |
E |
Dφ |
dφ |
|
|
#8 |
4.3 |
12.0 |
29.8 |
13.3 |
10.5 |
9.0 |
5.8 |
|
|
#10 |
5.3 |
12.0 |
29.8 |
13.3 |
|
|
1/4 |
6.4 |
12.0 |
29.8 |
13.3 |
|
|
1/4 |
6.4 |
16.0 |
32.8 |
13.3 |
|
|
5/16 |
8.4 |
16.0 |
32.8 |
14.5 |
|
|
3/8 |
10.5 |
16.0 |
32.8 |
14.5 |
|
|
1/2 |
13.0 |
22.0 |
41.0 |
19.5 |
|
|
9/16 |
15.0 |
30.0 |
51.0 |
25.0 |
|
|
5/8 |
17.0 |
30.0 |
51.0 |
26.0 |
|
|
11/6 |
19.0 |
30.0 |
51.0 |
27.0 |
|
|
3/4 |
21.0 |
30.0 |
51.0 |
28.0 | |
| 導線截面16～25mm2（美國線規4) 最大電流：Imax=115A 材質：紫銅 材料厚度：1.7mm |
|
型號 |
美制螺栓號 |
螺栓口直徑 |
尺寸 |
|
B |
L |
F |
E |
Dφ |
dφ |
|
|
#10 |
5.3 |
12.2 |
33.2 |
14.5 |
12.0
|
11.5
|
7.7
|
|
|
#10 |
5.3 |
16.5 |
33.7 |
13.5 |
|
|
1/4 |
6.4 |
12.2 |
33.2 |
14.5 |
|
|
1/4 |
6.4 |
16.5 |
33.7 |
13.5 |
|
|
5/16 |
8.4 |
16.5 |
33.7 |
13.5 |
|
|
3/8 |
10.5 |
16.5 |
33.7 |
13.5 |
|
|
1/2 |
13.0 |
22.0 |
42.5 |
19.5 |
|
|
9/16 |
15.0 |
30.0 |
51.0 |
24.0 |
|
|
5/8 |
17.0 |
30.0 |
51.0 |
25.0 |
|
|
11/16 |
19.0 |
30.0 |
51.0 |
26.0 |
|
|
3/4 |
21.0 |
30.0 |
51.0 |
27.0 | |
| 導線截面35～50mm2（美國線規2) 最大電流：Imax=160A 材質：紫銅 材料厚度：1.8mm |
|
型號 |
美制螺栓號 |
螺栓口直徑 |
尺寸 |
|
B |
L |
F |
E |
Dφ |
dφ |
|
|
#10 |
5.3 |
15.3 |
39.0 |
18.3 |
14.0 |
13.3 |
9.4 |
|
|
1/4 |
6.4 |
15.3 |
39.0 |
18.3 |
|
|
5/16 |
8.4 |
15.3 |
39.0 |
18.3 |
|
|
5/16 |
8.4 |
22.0 |
42.7 |
17.7 |
|
|
3/8 |
10.5 |
15.3 |
39.0 |
18.3 |
|
|
3/8 |
10.5 |
22.0 |
42.7 |
17.7 |
|
|
1/2 |
13.0 |
22.0 |
42.7 |
17.7 |
|
|
9/16 |
15.0 |
30.0 |
52.2 |
22.5 |
|
|
5/8 |
17.0 |
30.0 |
52.2 |
23.5 |
|
|
11/16 |
19.0 |
30.0 |
52.2 |
24.5 |
|
|
3/4 |
21.0 |
30.0 |
52.2 |
25.5 | |
| |
